Shure UA874WB Active Directional Antenna
- $622.94
($679.00 incl GST)
Active directional UHF antenna with integrated amplifier for improved wireless signal reception.
Out of Stock
Product is unavailable. Notify me when product is available
The UA874 replaces the UA870. UA874 uses a log periodic dipole array to produce a cardioid pattern towards the desired coverage area with greater rejection of RF signals outside the coverage area when compared to standard ½ wave omnidirectional antennas. An integrated amplifier with four gain settings compensate for varying degrees of coaxial cable signal loss.
The UA874 can be stand-mounted, suspended from the ceiling, or wall-mounted using the included swivel adapter bracket.
FEATURES
- Compatible with all Shure wireless receivers and antenna distribution systems that provide 12V DC bias
- Four-position gain selector switch
- Low-noise signal amplifier compensates for transmission loss in coaxial cable
- Integrated threaded adapter mounts easily to microphones stands
Connector Type
BNC, Female
Impedance
50 Ω
Power Requirements
10 to 15 V DC bias from coaxial connection, 75 mA
RF Frequency Range
UA874WB 470-900 MHz
Reception Pattern
3 dB Beam Width
70 degrees
Third-order Overload Intercept Point (OIP3)
>30 dBm
Antenna Gain
On Axis
7.5dBi
Signal Gain
±1 dB, Switchable
+12 dB, +6 dB, 0 dB, −6 dB
RF Overload LED Threshold
−5 dBm
RF overload LED does not operate for passive gain settings
Dimensions
UA874WB 316 x 359 x 36 mm (H x W x D)
Weight
UA874WB 317 g (11.2 oz.)
Operating Temperature Range
−18°C (0°F) to 63°C (145°F)
Storage Temperature Range
−29°C (-20°F) to 74°C (165°F)
- Shure UA874 Active Directional Antenna x 1 piece
2 Years
